WAGO 2000-1203 Feed-through/thru Terminal Block 1P 2 Wires

Product Description

The WAGO 2000-1203 is engineered for reliable electrical connections in Ex e II applications. This feed-through terminal block features a red design and accommodates one feed-through pole with two wires through its push-in connections. The nominal cross-section is one square millimeter, suitable for wire sizes from zero point fourteen mm squared to one point five mm squared or from twenty-four AWG to sixteen AWG. It is rated for a current of thirteen point five amps and is compatible with DIN-35 rails for mounting.

• Red color for easy identification
• Operating tool for simple installation
• Terminals designed for cage-clamp connections

Product Highlights

This terminal block is built for durability and safety in electrical installations, ensuring strong connections and ease of use.

Product Information

Standard Information

• Catalog Number: 2000-1203
• Manufacturer: WAGO

Technical Specifications

• Current Rating: 13.5 A
• Voltage Rating: 800 V
• Conductor Range: 16-24 AWG
• Conductor Material: Copper
• Material: Polyamide (PA66)
• Mounting: DIN Rail
• RoHS Indicator: Yes
• Dimensions: H48.5mm x W3.5mm x D32.9mm
