Wac en-24100-rb2 Remote Enclosed Electronic Transformer

Product Description

The WAC en-24100-rb2 is a remote enclosed electronic transformer designed to step down 120-volt primary voltage to a 24-volt secondary output for low-voltage lighting applications. Rated at 96 watts, it operates at a high switching frequency of 20 kHz, which reduces audible hum and supports stable, flicker-free lamp performance. The compact, enclosed housing measures 6.5 inches long by 1.625 inches wide by 1.25 inches high, making it suitable for concealed installation in ceilings, walls, or fixture canopies. It carries UL approval and is installed by licensed electricians working on low-voltage lighting systems in both residential and light commercial settings.

This transformer is suited for low-voltage LED and halogen lighting installations where a remote-mount power supply is required. Its enclosed design protects internal components from dust and incidental contact, making it appropriate for above-ceiling or in-wall rough-in locations. The 24-volt output is commonly used with low-voltage track, rail, and landscape lighting systems that require a remote transformer rather than an integrated driver. Electricians working on new construction or retrofit lighting projects will find the compact form factor useful in tight junction or canopy spaces.

Key Features

• 96-watt power rating supports multiple low-voltage fixtures on a single transformer
• 120-volt primary to 24-volt secondary step-down for low-voltage lighting circuits
• 20 kHz operating frequency minimizes audible hum and supports stable output
• Compact enclosed housing at 6.5 inches x 1.625 inches x 1.25 inches fits tight installation spaces
• UL listed for safe use in residential and light commercial electrical systems
• Remote mount design allows placement away from the fixture for flexible layout options

Compatibility

Designed as an OEM-style remote enclosed electronic transformer for low-voltage lighting systems requiring a 24-volt, 96-watt power supply with 120-volt input.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). Disconnect and lock out power at the breaker before wiring the primary side of the transformer. The enclosed housing must be mounted in a location that allows adequate ventilation to prevent overheating. Verify total connected load does not exceed the 96-watt rating before energizing the circuit.

Technical Specifications

• Power Rating: 96 watts
• Primary Voltage: 120 volts
• Secondary Voltage: 24 volts
• Operating Frequency: 20 kHz
• Length: 6.5 inches
• Width: 1.625 inches
• Height: 1.25 inches
• Transformer Type: Electronic
• Enclosure Type: Enclosed
• Certifications: UL Listed

Standard Information

• Brand: WAC
• Manufacturer Part Number: en-24100-rb2
