Victor 0781-5195 Two Stage Station Regulator

Product Description

The VICTOR 0781-5195 is a heavy-duty, two-stage station regulator engineered for hydrogen and LP gas distribution and pipeline systems. Built around a 4-port forged brass body with a zinc-aluminum housing cap, it delivers a rated outlet pressure range of 4 to 80 psig against a maximum inlet pressure of 200 psig. The 0.488 Cv flow coefficient provides uniform, accurate flow across a wide range of inlet cylinder pressures. Internals are secured with stainless steel bolts, and the housing cap carries nearly twice the yield strength of standard brass. Licensed HVAC and industrial gas technicians working on station supply systems are the primary installers.

This regulator is designed for use in gas distribution and pipeline station applications handling hydrogen or LP gas. The 025 CGA inlet connection pairs with a 9/16-18 LH(M) outlet connection, making it compatible with standard station supply configurations. The unit ships with 2-1/2-inch gauges featuring updated graphics and a 100 psig outlet gauge range, plus color-coded knobs for quick gas identification at the station panel. Its compact industrial footprint suits both new station builds and replacement installations where space is limited.

Key Features

• 4-port forged brass body with stainless steel bolts for corrosion resistance and structural integrity
• Zinc-aluminum housing cap with nearly twice the yield strength of brass
• 0.488 Cv flow coefficient for uniform delivery pressure across varying cylinder pressures
• Color-coded SLAM impact-absorbing safety knob with three-stage crumple zone for internal protection
• External self-reseating relief valve and sintered bronze inlet filter
• High-impact ABS gauge guard with enhanced-graphics gauges and 100 psig outlet range
• Side-entry and rear-entry inlet options for flexible station plumbing

Compatibility

Designed as a heavy-duty OEM-style station regulator for hydrogen and LP gas distribution and pipeline systems using a 025 CGA inlet connection and a 9/16-18 LH(M) outlet connection.

Installation Notes

Installation should be performed by a qualified gas technician or licensed pipefitter in accordance with applicable local codes and CGA guidelines. Shut off all upstream gas supply and verify zero line pressure before disconnecting or connecting any regulator. Inspect all fittings for leaks with an approved leak-detection solution after installation and before returning the system to service. Never use tools or force on the color-coded adjustment knob beyond normal hand pressure.

Technical Specifications

• Outlet Pressure Range: 4-80 psig
• Maximum Inlet Pressure: 200 psig
• Flow Coefficient (Cv): 0.488
• Inlet Connection: 025 CGA
• Outlet Connection: 9/16-18 LH(M)
• Gauge Size: 2-1/2 inches
• Outlet Gauge Range: 100 psig
• Body Material: Forged Brass (4-port)
• Housing Cap Material: Zinc-Aluminum
• Seat Mechanism: Stem Type
• Inlet Filter: Sintered Bronze
• Length: 8.8 inches
• Width: 8.6 inches
• Height: 8 inches
• Weight: 5.1 pounds
• Certifications: CGA E-4, UL 252 Listed, ASTM G-175
• Gas Types: Hydrogen, LP Gas
• Stages: Two Stage
• UPC: 716352559805

Standard Information

• Brand: VICTOR
• Manufacturer Part Number: 0781-5195
