Victor 0325-0101 Universal Welding Nozzle Type Un-j

Product Description

The VICTOR 0325-0101 is a Type UN-J universal nozzle designed for oxy-fuel welding, brazing, and heating applications. Built for multi-gas fuel use, the nozzle measures 5.4 inches in length and features a 65-degree tip angle with a 5/16 inch-27 thread. It accepts replaceable tip ends, making it a cost-effective option for shops that run varied tip sizes across a single handle. Licensed welders, fabricators, and maintenance technicians working with oxy-fuel equipment will find this nozzle fits standard professional torches and handles daily production demands.

The 0325-0101 nozzle is suited for industrial and general fabrication, repair and maintenance work, structural steel fabrication, and light fabrication tasks. Its standard bend geometry makes it a practical choice across a range of oxy-fuel processes where consistent flame control is required. The replaceable tip end design reduces downtime by allowing quick tip changes without replacing the full nozzle body.

Key Features

• Type UN-J universal nozzle for welding, brazing, and heating
• Compatible with multi-gas fuel applications
• 65-degree tip angle for standard bend geometry
• 5/16 inch-27 thread for secure torch connection
• Accepts replaceable tip ends to reduce operating cost
• Sold individually

Compatibility

Designed as an OEM-style replacement nozzle for professional oxy-fuel torch systems that accept Type UN-J universal nozzles with 5/16 inch-27 thread connections.

Installation Notes

Installation should be performed by a qualified welder or technician familiar with oxy-fuel equipment and applicable safety codes. Always shut off and bleed both oxygen and fuel gas supplies before removing or installing nozzle components. Use appropriate leak-detection solution after assembly to verify all connections are gas-tight before igniting the torch. Do not overtighten threaded connections, as this can damage the nozzle seat.

Technical Specifications

• Nozzle Type: UN-J Universal
• Fuel Type: Multi-Gas
• Tip Angle: 65 degrees
• Thread Size: 5/16 inches-27
• Length: 5.4 inches
• Width: 1.6 inches
• Weight: 0.2 pounds
• UPC: 716352102230

Standard Information

• Brand: VICTOR
• Manufacturer Part Number: 0325-0101
