Victaulic CE90731DEN 6 x 5 in Suction Diffuser

Product Description

The Victaulic CE90731DEN is a suction diffuser designed for effective fluid management in plumbing systems. Suitable for various applications, this diffuser connects the system side to the pump side seamlessly. It features a ductile iron body for durability and a stainless steel screen for filtration.

• Includes ANSI Class 150 flange for standard connections.
• Space-saving design builds up at a 90-degree angle from the pump.
• Pressure rated up to 365 PSI, ensuring robust performance.

Product Highlights

This suction diffuser protects pumps against cavitation while maximizing space in mechanical rooms.

Product Information

Standard Information

• Brand: Victaulic
• Part Number: CE90731DEN

Technical Specifications

• Nominal Size: 6 x 5 inches
• Connection Type: System Side Grooved X Pump Side Flange
• Screen Size: 20 Mesh
• Material Standard: ASTM A395
• Length: 15.8 inches
• Height: 13.1 inches
• Other Dimensions: 1-1/4-11-1/2 NPT
• Weight: 0
