Vickers by Danfoss 632873 Pressure Relief Valve 250 to 1000 psi

Product Description

The Vickers by Danfoss 632873 Pressure Relief Valve is designed to regulate system pressure within hydraulic systems. It features a pressure adjustment range from two hundred fifty psi to one thousand psi, providing versatility for various applications. This valve supports a maximum flow rate of eight gallons per minute, making it suitable for numerous fluid control tasks.

• Pressure adjustment range from 250 to 1000 psi
• Maximum flow rate of 8 gal/min
• Subplate or manifold mounting options

Product Highlights

This pressure relief valve offers reliable performance for hydraulic systems.

Product Information

Standard Information

• Brand: Vickers by Danfoss
• MPN: 632873

Technical Specifications

• Performance: Standard Performance
• Fluid Cleanliness: 20/18/15 micron
• Pressure [Max]: 2,000 psi
• Manual Override: No
• Valve Mount Type: Subplate/Manifold Mounted
• Seal Material: Buna-N
• Drain: Internal Drain
• Body Material: Cast Iron
• Model No.: RCT-03-D4-30
• Valve Type: Pressure Relief
• Flow [Max]: 8.00 gal/min
• Adjustment: Yes
• Pressure Adjustment Range (psi): 250 to 1,000
• Adjustment Type: Screw
• Remote: Yes
• Actuation Option: Proportional
• Weight: 1.0 LB
