Vickers by Danfoss 372552-1 Fixed Displacement Single Vane Pump

Product Description

The Vickers by Danfoss 372552-1 is a fixed displacement single vane pump designed for various hydraulic applications. This pump is suitable for industrial as well as mobile applications. It features balanced-vane-type construction, which improves efficiency and reliability.

• Rated flow capacities from six gallons per minute at one thousand two hundred rpm.
• Compatible with oil or synthetic fire-resistant fluids.
• Designed with right hand (clockwise) rotation.

Product Highlights

The Vickers single vane pump offers a compact solution for efficient fluid transfer in hydraulic systems.

Product Information

Standard Information

• Brand: Vickers by Danfoss
• Part Number: 372552-1

Technical Specifications

• Pressure Port: SAE-12
• Mounting Flange Code: 1
• Shaft Code + Outlet Port Code: 1A
• Integral Valve Configuration: w/o Integral Valves
• Design No.: 11
• Port Type: NPT
• Outlet Port Position: Opposite Inlet Port
• Shaft Diameter: 0.75 inches
• Shaft Key: 3/16 inches
• Flow Rate: 6 gallons per minute at 1200 rpm
• Max Pressure: 2500 psi
• Mounting: Flange Mount
• Pump Series: V20
• Displacement: 1.2 cubic inches per revolution
• Mounting Flange: SAE A, 2 Bolt
• Port Size: 1.25 inches
• Shaft Type: Straight with Key
• Seal Material: Buna-N
• Shaft Length: 2.66 inches
• Weight: 18.0 lbs
