Vickers by Danfoss 02-362429 Vickers D05 Solenoid Valve

Product Description

The Vickers by Danfoss solenoid valve, model number 02-362429, is designed for efficient operation in hydraulic systems. This valve is lever or knob operated and is categorized as D05 NFPA size, delivering reliable flow management.

• Rated for a maximum flow of twenty-eight point five gallons per minute.
• Compatible with petroleum oil and meets specific cleanliness standards.
• Constructed with a durable gray iron body and Buna-N seals.

Product Highlights

This solenoid valve is efficient for controlling fluid movement in hydraulic applications.

Product Information

Standard Information

• Brand: Vickers by Danfoss
• Part Number: 101909348

Technical Specifications

• Rated Flow [Max]: 28.5 gal/min
• Compatible Fluids: Petroleum Oil
• No. of Stages: Single Stage
• Fluid Cleanliness: 19/17/14 micron
• Spool Center Condition: B Port End
• Temperature Range [Max]: 158 °F
• Leakage: Standard Performance
• NFPA Size: D05
• Operation: Lever/Knob Operated
• Seal Material: Buna-N
• Temperature Range [Min]: -4 °F
• Body Material: Gray Iron
• Model No.: DG17V4-012A-10
• Reducer Module: No
• Pressure [Max]: 5076 psi
• Spool Spring Arrangement Code: A
• Mounting: Subplate/Manifold Mount
• Indicator Lights: No
• Weight: 1.0 LB
