Vargus 28134 Laydown Threading Insert

Product Description

The VARGUS 28134 is a laydown threading insert designed for precision thread-cutting operations on CNC lathes and turning centers. Part of the Vargus Microscope series, this insert seats in a laydown orientation, providing stable tool engagement and consistent thread form across production runs. It is used by machinists and toolroom technicians working with threaded components in metalworking, manufacturing, and industrial fabrication environments. The compact geometry and controlled dimensions make it well suited for threading applications where repeatability and insert rigidity are critical.

This threading insert is applied in single-point threading operations on lathes and turning equipment. It fits standard laydown threading toolholders compatible with the Vargus Microscope series. Typical use cases include threading of workpieces in general metalworking shops, job shops, and precision machining facilities. The insert ships individually and is ordered in single-unit quantities, making it practical for toolroom stock replenishment or targeted replacement of worn inserts.

Key Features

• Laydown seating design for stable, rigid tool engagement during threading
• Part of the Vargus Microscope series for consistent thread form and repeatability
• Compact profile measuring 2.95 inches in length, 0.75 inches in width, and 1.2 inches in height
• Lightweight at 0.65 pounds, minimizing load on toolholder setups
• Single-unit packaging supports precise inventory control and toolroom stocking

Compatibility

Designed for use with laydown threading toolholders compatible with the Vargus Microscope series. Refer to the Vargus catalog number 063-00221 for detailed holder and application matching.

Installation Notes

Installation should be performed by a qualified machinist following the toolholder manufacturer's seating and torque guidelines for laydown inserts. Power down and lock out the machine before changing inserts. Ensure the insert pocket is clean and free of chips or debris before seating the new insert. Verify thread form with a thread gauge on the first part after each insert change.
