Value Collection SO2145-32 Axial Fan 260 Cfm 230V

Product Description

The VALUE COLLECTION SO2145-32 is a square tube axial fan designed for AC-powered ventilation applications in HVAC, industrial, and equipment-cooling installations. Running on 230 volts AC, it delivers 260 CFM of airflow at speeds ranging from 2,900 to 3,400 RPM. The fan draws 0.280 amps, making it an efficient choice for continuous-duty applications. Ball bearing construction supports extended service life under sustained operation. At 6.3 inches high by 6.3 inches wide by 2.44 inches deep, it fits into compact inline or panel-mount configurations. Licensed HVAC technicians and industrial maintenance professionals are the primary installers of this unit.

This axial fan suits residential and light commercial HVAC equipment, refrigeration units, electronic enclosure cooling, and general-purpose forced-air ventilation. Its square tube housing simplifies direct panel or bulkhead mounting. The 260 CFM output and 230-volt single-phase AC input make it appropriate for equipment that requires consistent airflow across a moderate static pressure range. It is typically installed in situations where a compact, fixed-speed axial fan replaces a failed OEM unit or supplements existing ventilation.

Key Features

• 260 CFM airflow output for reliable forced-air ventilation
• 230-volt AC power input with 0.280-amp draw
• Speed range of 2,900 to 3,400 RPM for consistent performance
• Ball bearing construction for extended operational life
• Square tube housing measuring 6.3 x 6.3 x 2.44 inches for straightforward panel mounting
• Compact depth of 2.44 inches suitable for space-constrained installations

Compatibility

Designed as a general-purpose OEM-style replacement or upgrade axial fan for 230-volt AC ventilation and cooling applications in HVAC, refrigeration, and industrial equipment enclosures.

Installation Notes

Installation should be performed by a qualified HVAC technician or industrial electrician. Disconnect and lock out all power to the equipment before removing the existing fan or making any wiring connections, following applicable NEC guidelines. Verify that the mounting panel or housing can accommodate the 6.3 x 6.3 inch frame and that airflow direction is confirmed before final securing. Do not operate the fan outside its rated voltage range.
