Value Collection RNB14-10 Ring Terminal 6 Awg 3/8 Stud

Product Description

The VALUE COLLECTION RNB14-10 is a non-insulated circular ring terminal designed for crimp-style wire termination onto 3/8-inch threaded studs. Built with a copper contact, this terminal accepts 6 AWG conductors and provides a solid, low-resistance mechanical and electrical connection. At 1.28 inches in overall length and 0.63 inches in ring width, it fits standard panel, bus bar, and equipment grounding applications. Licensed electricians and qualified electrical technicians install this type of terminal in control panels, power distribution assemblies, and equipment grounding circuits where a bare, uninsulated termination is acceptable or required by the assembly design.

This ring terminal is suited for residential and commercial electrical panel work, HVAC equipment wiring, and industrial control enclosures wherever 6 AWG copper conductors require a reliable mechanical fastening point to a 3/8-inch stud. The non-insulated design is common in applications where post-crimp insulation sleeving is added separately or where the terminal block or enclosure provides its own insulation barrier. CSA Certified, cUL Listed, UL Listed, and RoHS Compliant ratings make it appropriate for use in installations subject to North American electrical codes and environmental compliance requirements.

Key Features

• Copper contact material for reliable conductivity and corrosion resistance
• Crimp connection type for fast, tool-secured termination without soldering
• Accepts 6 AWG wire, equivalent to 14.00 square millimeters conductor cross-section
• Fits 3/8-inch (9.53 mm) threaded studs common on bus bars and terminal blocks
• Non-insulated barrel suitable for applications with separate insulation or enclosed assemblies
• Carries UL Listed, cUL Listed, CSA Certified, and RoHS Compliant ratings

Compatibility

Designed as an OEM-style ring terminal for use with 6 AWG copper conductors requiring a 3/8-inch stud mounting point in electrical panel, HVAC equipment, and control enclosure applications.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize the circuit completely and verify zero voltage with a meter before terminating any conductor. Use a calibrated ratcheting crimping tool rated for the appropriate wire gauge to ensure a gas-tight, mechanically secure crimp. Do not attempt to solder this terminal after crimping, as post-crimp soldering can create stress fractures in the barrel and degrade the connection over time.
