Value Collection PS-MH-HPC1-133 Portable Hydraulic Cylinder

Product Description

The VALUE COLLECTION PS-MH-HPC1-133 is a portable hydraulic cylinder designed for high-force lifting, pressing, and positioning tasks in industrial and mechanical service applications. With a 29.7 cubic inch oil capacity and a 2.15-inch rod diameter, this cylinder delivers substantial working force in a self-contained package. The lowered height of 12.05 inches and maximum extended height of 18.11 inches define its usable stroke range. At 29.5 pounds, it is portable enough for field use while maintaining the structural integrity required for demanding work. Plunger internal threading and collar threading allow secure attachment to tooling or load fixtures. Hydraulic technicians, millwrights, and heavy-equipment mechanics are the primary installers and operators of this unit.

This portable hydraulic cylinder is suited for maintenance, repair, and overhaul environments where a compact, standalone hydraulic force source is required. Typical applications include bearing and bushing removal and installation, frame straightening, and component pressing in both shop and field settings. The threaded plunger and collar interfaces support use with standard hydraulic tooling adapters, making it a versatile addition to a hydraulic tool set used across industrial, construction, and heavy-equipment service operations.

Key Features

• 29.7 cubic inch oil capacity supports extended stroke operations without frequent reservoir replenishment
• 2.15-inch rod diameter provides a large bearing surface for high-load applications
• Stroke range from 12.05 inches (lowered) to 18.11 inches (maximum height) delivers 6.06 inches of working travel
• 1-9/16-16 plunger internal thread with 0.75-inch thread length enables secure tooling attachment
• 3-7/8-12 collar thread for stable base mounting or coupler connection
• 1.06-inch center hole diameter through the plunger for pull-force or pass-through applications

Compatibility

Designed as a portable, single-acting hydraulic cylinder for use with compatible hydraulic hand pumps or power units that match the cylinder port and pressure rating. No specific model compatibility was provided in the product data.

Installation Notes

Installation and operation should be performed by qualified hydraulic technicians or mechanics familiar with hydraulic cylinder safety practices. Always relieve all hydraulic pressure from the system before connecting or disconnecting the cylinder. Ensure all threaded connections are fully engaged and that the cylinder is positioned on a stable, level surface or secured to a fixture before applying load. Inspect seals, threads, and the plunger surface for damage before each use.
