Value Collection PS-MH-HPC1-094 Hydraulic Hose Connector

Product Description

The VALUE COLLECTION PS-MH-HPC1-094 is a steel female connector designed for hydraulic hose assemblies operating at pressures up to 10,000 psi. It features a 3/8 inch NPTF thread, providing a dry-seal tapered thread connection that resists leakage without relying solely on thread sealant. Rated for temperatures from -22 degrees F to 212 degrees F, this fitting handles a wide range of hydraulic fluid service conditions. At 0.64 pounds and measuring 1.77 inches in length, it is a compact, heavy-duty component suited for industrial and mobile hydraulic systems. Installation is performed by hydraulic technicians and mechanical contractors.

This connector is intended for use in high-pressure hydraulic hose assemblies where a female NPTF threaded termination is required. Typical applications include industrial machinery, mobile equipment hydraulics, and maintenance or repair operations requiring a direct-thread female coupling. The NPTF thread form conforms to ANSI B1.20.3 standards and is commonly used where a pressure-tight metal-to-metal seal is needed without additional fittings or adapters.

Key Features

• 10,000 psi maximum pressure rating for high-pressure hydraulic service
• 3/8 inch NPTF dry-seal tapered thread for leak-resistant metal-to-metal connection
• Steel construction for durability in demanding hydraulic environments
• Operating temperature range of -22 degrees F to 212 degrees F
• Compact form factor at 1.77 inches length and 0.64 pounds

Compatibility

Designed as an OEM-style replacement or service fitting for hydraulic hose assemblies requiring a 3/8 inch NPTF female connector rated to 10,000 psi.

Installation Notes

Installation should be performed by a qualified hydraulic technician or millwright. Depressurize the hydraulic system completely and relieve any residual pressure before removing or installing fittings. NPTF threads are self-sealing by design, but inspecting threads for damage before assembly is standard practice. Tighten to the fitting manufacturer's hand-tight-plus-turns specification and verify for leaks before returning the system to full operating pressure.
