Value Collection PS-MH-HPC1-040 Hydraulic Pressure Gauge

Product Description

The VALUE COLLECTION PS-MH-HPC1-040 is a dry hydraulic pressure gauge rated from 0 to 10,000 psi, designed for use in high-pressure hydraulic systems. The 4-inch diameter face provides a large, readable dial for monitoring system pressure in demanding service environments. The 1/4 NPTF gauge connection ensures a leak-free threaded fit to standard hydraulic ports. With no liquid fill, this gauge is suited for applications where vibration levels are low enough that dampening fluid is not required. Hydraulic technicians and fluid power mechanics install this gauge when direct pressure readings are needed during system setup, diagnostics, or ongoing pressure monitoring.

This gauge is appropriate for use on hydraulic power units, presses, cylinders, manifolds, and test stands operating within the 0 to 10,000 psi range. The 1/4 NPTF port makes it compatible with standard hydraulic plumbing found in both industrial and mobile equipment environments. Its compact 4-inch face fits standard panel cutouts and gauge mounting brackets. Dry construction makes it a straightforward drop-in for static or low-vibration hydraulic circuits where a liquid-filled gauge is not specified.

Key Features

• Wide 0 to 10,000 psi range covers high-pressure hydraulic circuit requirements
• 4-inch face diameter for clear, at-a-glance pressure readings
• 1/4 NPTF gauge connection provides a pressure-tight threaded seal
• Dry gauge construction suited for low-vibration hydraulic applications
• Compact form factor fits standard gauge panels and bracket mounts

Compatibility

Designed as a direct-fit replacement or new-installation dry pressure gauge for hydraulic systems plumbed with 1/4 NPTF gauge ports and operating within a 0 to 10,000 psi pressure range.

Installation Notes

Installation is typically performed by a hydraulic technician or fluid power mechanic. Depressurize and lock out the hydraulic circuit completely before removing or installing any gauge. Apply an appropriate thread sealant rated for hydraulic service to the NPTF threads; do not over-tighten, as this can crack the gauge body. Verify the system operating pressure does not exceed the 10,000 psi gauge rating before returning the circuit to service.
