Value Collection PC72GS-14 Male Swivel Branch Tee Fitting

Product Description

The VALUE COLLECTION PC72GS-14 is a male swivel branch tee push-to-connect tube fitting designed for pneumatic and fluid distribution lines where a single tube run needs to branch off a threaded port. Constructed from polyoxymethylene (POM), the fitting offers good chemical resistance and dimensional stability for low-to-medium pressure applications. It accepts tubing with a 5/32 inch outside diameter and connects to a 1/4 inch NPT male thread. The swivel design allows the branch leg to rotate during installation, reducing stress on the tubing and simplifying alignment in tight plumbing layouts. Rated to 150 psi, it is suited for compressed air, water, and compatible fluid systems.

This fitting is commonly installed in light industrial equipment, pneumatic control panels, instrumentation tubing runs, and fluid-transfer assemblies where a compact branch connection is needed. The push-to-connect mechanism allows tool-free tube insertion and release, making it practical for field service and panel assembly work. Plumbers, pipefitters, and instrumentation technicians working on low-pressure distribution systems will find the swivel branch tee useful where fixed-body fittings would create tubing alignment problems.

Key Features

• Push-to-connect mechanism allows tool-free tube insertion and removal
• Swivel branch body simplifies tube alignment during installation
• Polyoxymethylene (POM) construction provides chemical resistance and dimensional stability
• Rated to 150 psi for use in compressed air and compatible fluid systems
• 1/4 inch NPT male thread for standard port connections
• Accepts 5/32 inch OD tubing

Compatibility

Designed as a standard-style replacement or new-installation push-to-connect branch tee for pneumatic and fluid distribution systems using 5/32 inch OD tubing and 1/4 inch NPT threaded ports.

Installation Notes

Installation of this fitting should be performed by a qualified pipefitter, plumber, or instrumentation technician familiar with push-to-connect pneumatic fittings. Depressurize and isolate the system before removing or installing any fittings. Ensure the NPT male threads are wrapped with thread sealant tape appropriate for the media being carried before torquing into the port. Verify tubing is cut square and free of burrs before inserting into the push-to-connect collet to ensure a proper seal.
