Value Collection MSTI0-800180-100BX 8-32 Truss Head Screw

Product Description

The VALUE COLLECTION MSTI0-800180-100BX is a truss head machine screw designed for general fastening applications across mechanical, electrical, and light industrial assemblies. It features an 8-32 unified coarse thread with a 3/16-inch length measured under the head. The truss head profile provides a wider, low-profile bearing surface, distributing clamping load across a larger area than a standard pan or round head. The slotted drive accepts a flat-blade screwdriver and keeps installation straightforward where Phillips or combination drivers are not available. Material is Grade 2 steel with a zinc plating finish for basic corrosion resistance. This screw ships in a minimum quantity of 100 per order and is manufactured to ASME B18.6.3 standards.

These screws are used in a wide range of trade and manufacturing settings including electrical enclosure assembly, control panel fabrication, HVAC equipment panels, light fixture mounting, and general sheet metal work. The 8-32 thread size is one of the most common machine screw thread designations in inch-system applications and sees regular use in residential and light commercial equipment assemblies. Installers typically stock this size for panel cover attachment, component mounting, and field repairs where OEM fasteners need replacement.

Key Features

• 8-32 unified coarse thread for broad compatibility with standard inch-system tapped holes and nuts
• Truss head profile provides wide, low-profile bearing surface for improved load distribution
• Slotted drive accommodates flat-blade screwdrivers and standard manual tools
• Grade 2 steel construction meets ASME B18.6.3 dimensional and mechanical standards
• Zinc plating provides basic corrosion resistance for indoor and light-duty applications
• Sold in 100-count increments for convenient shop and job-site stocking

Compatibility

Designed as a general-purpose replacement or stock fastener for any application requiring an 8-32 x 3/16-inch truss head slotted machine screw in inch-system assemblies.

Installation Notes

Install with a flat-blade screwdriver sized to fit the slot width; an undersized blade risks cam-out and slot damage. Always verify the mating thread or nut is rated for 8-32 thread engagement before driving. When installing in electrical enclosures or control panels, de-energize the equipment fully before performing any fastener work in accordance with applicable NFPA 70 lockout-tagout requirements. Do not over-torque into thin sheet metal; use a thread-forming or captive nut where pull-out strength is a concern.
