Value Collection LW7S00500-100BX M5 Split Lock Washer Steel

Product Description

The VALUE COLLECTION LW7S00500-100BX is a metric split lock washer sized for M5 fasteners. It is manufactured from steel with a bright, uncoated finish and conforms to DIN 127B. The washer features an inside diameter ranging from 5.1 to 5.4mm, a maximum outside diameter of 9.2mm, and a thickness of 1.2mm. Split lock washers are installed under a nut or bolt head to resist loosening caused by vibration or torque relaxation. This part is sold in a minimum order quantity of 100 pieces and is used by electricians, HVAC technicians, plumbers, and mechanical contractors wherever metric M5 fasteners require a vibration-resistant locking method.

This washer is suited for general mechanical assembly and maintenance applications in residential and commercial settings. It is appropriate wherever an M5 screw or bolt is used and vibration resistance is required. The uncoated finish makes it compatible with indoor applications and assemblies where a post-installation coating or plating is applied by the installer. Typical uses include panel mounting, equipment brackets, pipe hangers, and similar structural connections requiring metric hardware.

Key Features

• DIN 127B standard metric split lock washer for M5 fasteners
• Inside diameter 5.1 to 5.4mm for consistent fit on M5 screws and bolts
• Maximum outside diameter of 9.2mm and thickness of 1.2mm
• Steel construction with bright, uncoated finish
• Resists fastener loosening under vibration and torque relaxation
• Sold in multiples of 100 pieces for shop and job-site stocking

Compatibility

Designed for use with M5 metric screws and bolts. Conforms to fastener standard DIN 127B. Suitable for general mechanical, electrical, and HVAC assembly applications using M5 metric hardware.

Installation Notes

Install the split lock washer between the bearing surface of the nut or bolt head and the workpiece before final torque is applied. Ensure the fastener thread and mating surface are clean and free of debris before assembly. This is a general-purpose mechanical fastener component installable by any trade using M5 metric hardware. No special tools are required beyond standard metric wrenches or drivers.
