Value Collection BD-29895 Cartridge Time Delay Fuse 7A 250V

Product Description

The VALUE COLLECTION BD-29895 is a mini cartridge time delay fuse rated at 7 amps and 250 volts, designed for overcurrent protection in low-voltage control circuits and light-duty electrical equipment. The glass body allows for quick visual inspection of the fuse element without removal. Time delay construction tolerates brief inrush currents common during motor start-up or transformer energization, reducing nuisance trips. This fuse ships in a pack of 5 and weighs approximately 0.01 pounds. Electricians and HVAC technicians routinely use fuses of this type when servicing control boards, transformers, and accessory circuits requiring reliable short-circuit protection.

This fuse is suited for residential and light commercial applications where mini cartridge fuses are specified in control panels, HVAC equipment, appliances, and electronic equipment. The 1.25-inch overall length and 0.25-inch diameter conform to standard mini fuse holder dimensions, making it a straightforward drop-in replacement during routine service calls. The time delay characteristic is particularly useful in circuits with small inductive loads where momentary current spikes occur at startup.

Key Features

• 7 amp, 250 volt rating suitable for control circuit protection
• Time delay fuse element tolerates startup inrush without nuisance tripping
• Glass body allows visual inspection of fuse element
• Mini cartridge form factor: 1.25 inches OAL, 0.25 inches diameter
• CSA Certified and UL Listed
• Sold in a pack of 5 for service stock

Compatibility

Designed as a standard mini cartridge fuse replacement for control circuits, HVAC equipment, appliances, and light-duty electrical panels requiring a 7 amp, 250 volt, time delay cartridge fuse in a 1.25-inch by 0.25-inch mini form factor.

Installation Notes

De-energize all circuits and verify zero voltage with a meter before replacing any fuse. Mini cartridge fuses seat into panel-mount or inline fuse holders and require no tools beyond a fuse puller or needle-nose pliers. Always replace with a fuse of identical amperage, voltage, and timing class — substituting a fast-acting fuse in a time delay application may cause repeated nuisance openings. Work performed in electrical panels must comply with applicable NEC requirements and local codes.
