Value Collection BD-29614 Cartridge Fast-acting Fuse 25A 600V

Product Description

The VALUE COLLECTION BD-29614 is a cartridge-style, fast-acting fuse rated at 25 amps and 600 volts, with an interrupting capacity of 100 kiloamps at AC. It measures 1-1/2 inches overall length with a 13/32-inch diameter body. Fast-acting fuses respond immediately to overcurrent conditions without intentional delay, making them appropriate for circuits where downstream components cannot tolerate sustained fault current. Licensed electricians and maintenance technicians install these fuses in fusible disconnect panels, fused switch enclosures, and industrial control cabinets where branch-circuit or supplemental protection is required.

This fuse is suited for residential, commercial, and light industrial electrical installations where 600-volt-rated cartridge fuses are specified. Its compact cylindrical form fits standard Class K or midget fuse blocks and holders designed for the 13/32-inch diameter form factor. It is appropriate for protecting motors, transformers, HVAC control circuits, and general branch-circuit wiring that requires fast-acting overcurrent response.

Key Features

• 25-amp current rating with fast-acting response for immediate overcurrent interruption
• 600-volt AC voltage rating suitable for commercial and industrial circuits
• 100 kA interrupting capacity at AC for high-fault-current environments
• Cartridge body measures 1-1/2 inches OAL x 13/32 inches diameter for standard fuse-holder fitment
• CSA Certified and UL Listed for code-compliance on permitted installations
• Sold in packs of 10, minimum order quantity of 1 pack

Compatibility

Designed as a standard-form cartridge fast-acting fuse for use in 600-volt-rated fuse blocks and holders accepting a 13/32-inch diameter, 1-1/2-inch OAL cartridge body.

Installation Notes

Installation must be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the circuit before removing or installing fuses. Use an appropriate fuse puller rated for the voltage class — never handle energized fuse elements with bare hands or uninsulated tools. Verify the replacement fuse amperage and voltage rating match the circuit requirement before closing the disconnect.
