Value Collection BD--12145-3 90 Degree Elbow 1/2 Inch Npt

Product Description

The VALUE COLLECTION BD--12145-3 is a 90 degree forged carbon steel elbow designed for high-pressure piping systems in commercial and industrial applications. Finished in black, this fitting carries a Class 3000 pressure rating and features female NPT end connections on both ports. At 1/2 inch nominal size, it is suited for gas and liquid service lines where a reliable direction change is required. Licensed pipefitters and plumbers install this type of fitting when routing pipe through tight spaces or around obstructions in mechanical rooms, process piping, and utility systems.

This elbow is a standard threaded pipe fitting used in 1/2 inch NPT piping systems that handle gases or liquids within the pressure limits of a Class 3000 forged carbon steel fitting. It is appropriate for both above-ground and concealed piping assemblies in commercial mechanical and industrial process environments. The black finish is standard for carbon steel threaded fittings in non-corrosive dry or gas service. This SKU ships in a package quantity of 5 units per order.

Key Features

• 90 degree elbow configuration for perpendicular direction changes in threaded pipe runs
• Forged carbon steel construction for strength and pressure integrity
• Class 3000 rated at 3000 psi for gas and liquid service
• 1/2 inch NPT female threaded end connections on both ports
• Black finish standard for carbon steel threaded fittings
• Sold in a package quantity of 5 units

Compatibility

Designed as an OEM-style threaded pipe fitting compatible with standard 1/2 inch NPT piping systems in commercial and industrial gas and liquid service applications.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable mechanical and plumbing codes. Shut off all line pressure and bleed residual gas or fluid before disassembling any existing piping. Apply a code-approved thread sealant or PTFE tape to the male threads before making up the connection. Do not exceed the pressure and temperature ratings of the fitting or the piping system.
