Value Collection B7S075C625 Threaded Stud 3/4-10 6.25in Steel

Product Description

The VALUE COLLECTION B7S075C625 is a fully threaded stud designed for high-strength fastening applications. It carries a 3/4-10 UNC thread profile with a 6.25-inch overall length, meaning threads run the entire shaft with no unthreaded shank. Manufactured from Grade B7 alloy steel in an uncoated finish, this stud meets the demands of bolted assemblies where tensile strength and thread integrity are critical. The Class 2A thread fit provides a standard external thread tolerance suitable for general industrial and mechanical fastening. Licensed tradespeople in mechanical, structural, and industrial maintenance work commonly specify this stud where a double-nut or flange-mounted fastening arrangement is required.

This stud is appropriate for structural assemblies, pipe flange connections, equipment mounting, and general industrial fastening where a full-length threaded fastener is specified. Grade B7 alloy steel is a common requirement in pressure vessel, flange bolt, and high-load bracket applications. The uncoated finish is suited for environments where a secondary coating or plating will be applied, or where bare steel is acceptable for the service condition. It is sold individually and is compatible with standard 3/4-10 UNC hex nuts and threaded hardware.

Key Features

• Full-length 3/4-10 UNC thread along the entire 6.25-inch shaft — no unthreaded shank
• Grade B7 alloy steel construction for elevated tensile and yield strength
• Class 2A thread fit tolerance for compatibility with standard 3/4-10 UNC nuts and threaded inserts
• Uncoated finish allows for field painting, plating, or use as-is where bare steel is acceptable
• UNSPSC Code 31161618 for procurement and catalog classification

Compatibility

Designed for use with standard 3/4-10 UNC threaded nuts, couplings, and hardware. Suitable as a replacement or stock fastener in any application specifying a Grade B7 fully threaded stud at 3/4-10 thread size and 6.25-inch overall length.

Installation Notes

Installation is typically performed by millwrights, pipefitters, or mechanical maintenance technicians. Ensure mating threaded components — nuts, couplings, or tapped holes — are also rated for 3/4-10 UNC thread form before assembly. Inspect threads for damage or contamination before use. Follow applicable torque specifications from the equipment manufacturer or relevant ASME, ASTM, or ANSI standards for the specific joint design.
