Value Collection B7S075C525 Fully Threaded Stud 3/4-10

Product Description

The VALUE COLLECTION B7S075C525 is a fully threaded stud designed for high-strength fastening applications in mechanical, structural, and industrial assemblies. Manufactured from alloy steel to ASTM A193 Grade B7 specifications, this stud carries a 3/4-10 UNC thread form and measures 5.25 inches in overall length. The full-thread design means the entire shank is threaded, giving installers maximum flexibility in engagement depth and nut positioning. At 0.55 pounds, the stud is lightweight relative to its size while delivering the clamping load expected from a Grade B7 fastener. The uncoated finish is suitable for standard service environments or for applications where a field-applied coating will be used.

This fully threaded stud is commonly used in bolted flange connections, equipment mounting, and structural steel assemblies where high tensile strength and reliable thread engagement are required. It is appropriate for both shop fabrication and field installation work performed by pipefitters, millwrights, ironworkers, and maintenance mechanics. The 3/4-10 thread size is a standard coarse-thread configuration widely used in industrial piping, pressure vessel, and machinery applications.

Key Features

• Full-length 3/4-10 UNC thread along the entire 5.25-inch length for maximum engagement flexibility
• ASTM A193 Grade B7 alloy steel construction for high tensile and yield strength
• Thread Fit Class 2A provides standard tolerances for use with Class 2B nuts and tapped holes
• Uncoated finish suitable for field coating or use in dry service environments
• Single-piece solid stud with no reduced shank or partial thread zones

Compatibility

Designed as a standard 3/4-10 UNC fully threaded stud for use with Class 2B nuts and tapped holes in industrial, mechanical, and structural fastening applications.

Installation Notes

Installation is typically performed by pipefitters, millwrights, or maintenance mechanics using standard hand and power tools. Confirm mating nut or tapped-hole thread class matches Class 2B before assembly. De-energize, depressurize, and isolate any system before replacing fasteners in live service. Apply thread lubricant or anti-seize compound as required by the governing specification or engineering drawing.
