Value Collection 934-000-035 Ball End Mill 3/64 in 2 Flute

Product Description

The VALUE COLLECTION 934-000-035 is a cobalt ball end mill designed for precision milling in metalworking and machining applications. Built from M42 cobalt high-speed steel, this stub-length double-end mill measures 0.0469 inches (3/64 inches) in diameter with a 1/16 inch length of cut and a 2 inch overall length. It features two flutes with a variable helix angle between 35 and 40 degrees, supporting both roughing and finishing operations. The bright/uncoated finish makes it suitable for a wide range of primary workpiece materials. Its center-cutting capability and right-hand cutting direction are standard for vertical milling setups.

This ball end mill is suited for milling operations on steel, stainless steel, cast iron, aluminum and non-ferrous metals, high-temperature alloys, and hardened materials. The double-end design provides two usable cutting ends, extending tool life between replacements. It is well matched for small-radius contouring, slotting, and profile work in tool rooms, job shops, and production machining environments. The straight cylindrical shank fits standard collet and end mill holders commonly found on VMCs, manual mills, and CNC machining centers.

Key Features

• M42 cobalt high-speed steel construction for heat and wear resistance in demanding materials
• Variable helix angle (35 to 40 degrees) reduces chatter and improves surface finish
• Double-end design provides two cutting ends per tool
• Center-cutting geometry allows direct plunge entry
• Right-hand spiral flutes with bright/uncoated finish for versatile material compatibility
• Rated for roughing and finishing material removal in a single tool

Compatibility

Designed for use on steel, stainless steel, cast iron, aluminum and non-ferrous metals, high-temperature alloys, and hardened materials. Fits standard collet systems and end mill holders accepting a 3/16 inch straight-cylindrical shank.

Installation Notes

Installation is performed by machinists or tool and die professionals. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the shank fully into the collet or holder and torque the retention mechanism per the holder manufacturer specification. Confirm runout with a dial indicator before beginning a cut, particularly given the small diameter of this tool.
