Value Collection 830-3308 Steel Transfer Screw Set 4 Piece

Product Description

The VALUE COLLECTION 830-3308 is a four-piece steel transfer screw set covering four common metric thread sizes: M6x1.00, M8x1.25, M10x1.50, and M12x1.75. Transfer screws are used to locate and transfer hole center positions from one workpiece to a mating part without the need for layout tools or measuring instruments. Each screw is machined with a sharp point at the tip that presses a precise center mark into the receiving material when the parts are pressed together. The set is constructed from steel for durability in shop use. Machinists, toolmakers, and general machine shop personnel will find this set useful for accurate hole transfer work across a range of common metric fastener sizes.

This transfer screw set is suited for metalworking, machine shop, and fabrication environments where accurate hole pattern transfer is required. The four included sizes cover the most frequently encountered metric thread pitches in general mechanical and structural applications. Typical use cases include aligning bolt patterns when fitting covers, flanges, brackets, or mating components during assembly or repair work. The set is packaged as a single unit with all four screws included.

Key Features

• Four-piece set covering M6x1.00, M8x1.25, M10x1.50, and M12x1.75 thread sizes
• Steel construction for lasting shop durability
• Sharp transfer point marks precise hole center locations on mating workpieces
• Eliminates layout error when transferring bolt or hole patterns
• Compact set suitable for general machine shop and fabrication use

Compatibility

Designed as a general-purpose transfer screw set for use in threaded holes with metric thread profiles M6x1.00, M8x1.25, M10x1.50, and M12x1.75 in metalworking and fabrication applications.

Installation Notes

Transfer screws are installed by threading each screw into the existing tapped hole of the reference part so the pointed tip faces outward. The mating workpiece is then pressed or tapped firmly against the reference part to transfer the center mark. No special tools are required beyond hand tightening. Remove transfer screws promptly after marking to avoid tip damage and store in the provided set packaging.
