Value Collection 744026PS M2.6 Split Lock Washer Spring Steel

Product Description

The VALUE COLLECTION 744026PS is a metric split lock washer designed for use with M2.6 screws. Made from spring steel with a bright uncoated finish, it creates a locking action under fastener load by biting into both the mating surface and the fastener bearing face as the joint is tightened. The washer meets DIN 127 fastener standards and carries a hardness rating of 44-51 HRC, providing reliable resistance to loosening in vibration-prone assemblies. This washer is sold individually, with a minimum order quantity of 100 pieces per order. Electricians, mechanical assemblers, and equipment technicians working with small metric fasteners are the typical end users.

This split lock washer is suited for light-duty metric fastening applications where M2.6 hardware is specified. Common applications include control panel assembly, electrical enclosure work, small equipment fabrication, and electronic component mounting where metric hardware is required. The DIN 127 standard governs dimensional tolerances and material requirements, making this washer a direct fit wherever that specification is called out.

Key Features

• DIN 127 compliant metric split lock washer for M2.6 screw size
• Spring steel construction with 44-51 HRC hardness for reliable locking force
• Bright uncoated finish suitable for dry or controlled-environment applications
• Inside diameter range of 2.60 to 2.90 mm accommodates standard M2.6 fastener shanks
• 0.60 mm thickness with a maximum outside diameter of 5.10 mm
• Sold as a single piece with a minimum order quantity of 100 units

Compatibility

Designed for use with M2.6 metric screws and bolts per DIN 127 dimensional standards. Verify mating surface hardness and fastener thread class before installation to ensure proper locking performance.

Installation Notes

Install with the split gap positioned so the washer bears evenly under the fastener head or nut. Tighten the fastener to the torque specification defined by the assembly drawing or fastener manufacturer for the applicable thread class and material. Do not reuse split lock washers once a joint has been disassembled, as the locking geometry is compromised after initial compression. Follow all applicable mechanical assembly standards for the equipment being serviced.
