Value Collection 644713PS Hex Head Cap Screw M14 X 2

Product Description

The VALUE COLLECTION 644713PS is a metric hex head cap screw designed for general mechanical fastening applications where precision threading and reliable clamping strength are required. Manufactured from Grade 8.8 steel with a bright uncoated finish, this fastener conforms to DIN 931 and ISO 4014 standards for partially threaded hex bolts. The M14 x 2.00 thread size and 130 mm length under head make it suitable for medium-to-heavy-duty assemblies. At 0.386 pounds per piece, it offers substantial material mass for its class. Installation requires a 22 mm hex wrench or socket. Licensed mechanics, millwrights, and maintenance technicians are the typical installers.

This screw is used in structural and mechanical assemblies across industrial, commercial, and OEM manufacturing environments. The partial threading is standard for through-bolt and clearance-hole applications where the unthreaded shank provides shear resistance and proper bearing load distribution. It is well suited for bolted flange connections, equipment frames, machinery bases, and similar heavy-duty joint configurations that follow metric fastener standards.

Key Features

• M14 x 2.00 metric thread with 130 mm length under head per DIN 931 and ISO 4014
• Grade 8.8 steel construction provides high tensile and yield strength for demanding applications
• Partially threaded shank delivers shear resistance in clearance-hole and through-bolt installations
• Bright uncoated finish suitable for use in dry indoor environments or where field coating will be applied
• 22 mm hex drive compatible with standard metric wrenches and sockets
• UNSPSC Code 31161501 for procurement and catalog classification

Compatibility

Designed as an OEM-style metric replacement fastener conforming to DIN 931 and ISO 4014 standards, compatible with M14 x 2.00 threaded holes in metric-standard mechanical assemblies and structures.

Installation Notes

Installation should be performed by a qualified mechanic or millwright familiar with metric fastener specifications and applicable torque standards. Always verify that the mating threaded hole or nut is also rated for Grade 8.8 or equivalent before assembly. Do not mix metric and unified thread fasteners in the same joint. Follow the applicable equipment manufacturer torque specifications and relevant standards such as ASME or ISO bolted joint guidelines when determining final torque values.
