Value Collection 51025 Snap Tite Pressure Test Plug

Product Description

The VALUE COLLECTION 51025 is a snap-style pressure test plug used to temporarily seal pipe openings during pressure testing procedures. The plug seats with a snap-fit action, allowing fast installation and removal without threading or tools. With an outer diameter of 2.75 inches and a length of 1.19 inches, this plug is sized for use in standard pipe ends and test port fittings. Plumbers, pipefitters, and mechanical contractors use pressure test plugs like this one to isolate sections of a piping system and verify integrity before commissioning or after repair work.

This snap tite test plug is suited for residential and light commercial plumbing and mechanical applications where temporary pipe sealing is required during hydrostatic or low-pressure pneumatic testing. Its compact length makes it appropriate for tight-access test points. The snap-fit design allows a single technician to stage multiple test points quickly without additional fasteners or adhesives.

Key Features

• Snap-fit design allows tool-free installation and removal
• 2.75-inch outer diameter fits standard pipe openings of that nominal size
• 1.19-inch length suits shallow test ports and tight-clearance locations
• Lightweight at 0.49 pounds for easy handling and staging
• Sold individually, one plug per package

Compatibility

Designed as an OEM-style replacement or aftermarket option for snap-fit pressure test plug applications in standard plumbing and mechanical piping systems requiring a 2.75-inch OD test plug.

Installation Notes

Pressure test plugs are typically installed by licensed plumbers or pipefitters in accordance with the International Plumbing Code (IPC) or applicable local codes governing pressure testing procedures. Before installing the plug, ensure the pipe section is depressurized and drained. Press the plug firmly into the pipe opening until the snap-fit seats fully. Remove the plug only after the system has been fully depressurized following the test procedure.
