Value Collection 47415 M10 High Collar Split Lock Washer

Product Description

The VALUE COLLECTION 47415 is a metric high collar split lock washer designed for use with M10 screws. Made from Grade 2 steel with a bright, uncoated finish, this washer provides a mechanical locking action that resists loosening caused by vibration and dynamic loads. The high collar design increases axial load-bearing surface area compared to standard split lock washers. Inside diameter ranges from 10.2 mm to 10.7 mm, with a maximum outside diameter of 16 mm and a thickness of 2.5 mm. It conforms to DIN 7980 fastener standards. Installers in mechanical, industrial, and trade applications rely on this washer as part of a secure bolted joint assembly.

This washer is suited for general-purpose metric fastener assemblies where vibration resistance is required. Typical applications include HVAC equipment mounting, electrical enclosure hardware, plumbing fixture attachment, and light structural connections using M10 metric fasteners. The uncoated bright finish makes it appropriate for indoor or protected installations. This part is sold individually and must be ordered in multiples of 50 to meet the minimum order quantity.

Key Features

• High collar split lock washer design increases bearing surface and locking effectiveness
• Conforms to DIN 7980 fastener standard for metric hardware
• Grade 2 steel construction provides reliable mechanical performance in general-purpose applications
• Bright uncoated finish suitable for dry, protected indoor environments
• Inside diameter range of 10.2 mm to 10.7 mm fits standard M10 fasteners
• 2.5 mm thickness meets DIN 7980 dimensional requirements

Compatibility

Designed for use with M10 metric screws and bolts in assemblies conforming to DIN 7980 dimensional standards.

Installation Notes

Installation is performed by mechanical, electrical, or plumbing tradespeople as part of a bolted joint assembly. Always ensure mating fastener and hole dimensions are compatible with M10 metric specifications before installation. Place the washer between the fastener head and the mating surface with the split ends contacting the workpiece. Do not reuse lock washers that have been fully compressed, as the locking function may be degraded.
