Value Collection 464.19.2424 Membrane Disc Coupling Ss

Product Description

The VALUE COLLECTION 464.19.2424 is a flexible membrane disc coupling designed for shaft-to-shaft power transmission in precision mechanical and industrial drive applications. Constructed entirely from stainless steel, this compact coupling measures 0.75 inches in outside diameter and 0.77 inches in overall length, with a 0.25 inch inside diameter bore. It accommodates minor angular and parallel shaft misalignment while transmitting torque up to 170 inch-pounds. The membrane disc design provides torsional rigidity with flexible axial compliance, making it suitable for motion control, instrumentation, and light industrial drive systems. Installation is typically performed by mechanical technicians and machine builders working with precision drive assemblies.

This coupling is used in applications where a compact, corrosion-resistant connector is required between drive shafts in tight-clearance assemblies. The stainless steel construction makes it appropriate for environments with moisture exposure or washdown requirements. Typical use cases include servo drive systems, encoder connections, pump shafts, and other precision torque transmission setups where shaft flexibility compensation is needed without sacrificing torque capacity.

Key Features

• Stainless steel disc membrane construction for corrosion resistance and durability
• Rated torque capacity of 170 inch-pounds for reliable power transmission
• Compact 0.75 inch OD and 0.77 inch OAL for tight-clearance installations
• 0.25 inch inside diameter bore for small-shaft drive connections
• Membrane disc style accommodates minor shaft misalignment without sacrificing torsional stiffness

Compatibility

Designed as an OEM-style replacement or direct-fit flexible membrane disc coupling for precision mechanical drive assemblies requiring a 0.75 inch OD, 0.25 inch bore, stainless steel shaft coupling.

Installation Notes

Installation should be performed by qualified mechanical technicians familiar with precision shaft alignment procedures. Ensure all connected drive equipment is de-energized and locked out before handling or replacing couplings. Verify shaft sizes and bore clearances before installation to prevent binding or premature wear. Do not exceed the rated torque specification during operation.
