Value Collection 450-003NL 1/2 Inch Brass 90 Elbow Mpt Class 125

Product Description

The VALUE COLLECTION 450-003NL is a 1/2 inch Class 125 brass pipe 90-degree elbow designed for threaded piping systems. It features male pipe thread (MPT) ends on both connections and carries a 125 psi pressure rating. Constructed with a red brass finish, this fitting is suited for plumbing, HVAC, and general fluid-handling applications where a reliable right-angle directional change is needed in a threaded line. Licensed plumbers and pipefitters are the typical installers for this type of fitting.

This elbow fits standard 1/2 inch NPT threaded pipe and is appropriate for residential and light commercial piping installations. Common uses include water supply lines, hydronic heating circuits, compressed air distribution, and similar low-to-medium pressure threaded systems. Its compact dimensions make it practical in tight mechanical spaces where a 90-degree turn is required without additional fittings or adapters.

Key Features

• 90-degree elbow geometry for right-angle directional changes in threaded piping runs
• MPT (male pipe thread) ends on both sides for standard NPT threaded connections
• 125 psi pressure rating suitable for water, air, and general fluid service
• Red brass construction offering corrosion resistance in wet and humid environments
• Compact profile at 2.75 inches height and 1.75 inches width and length

Compatibility

Designed as a standard Class 125 replacement or new-installation fitting for 1/2 inch NPT threaded pipe systems in residential and light commercial plumbing and HVAC applications.

Installation Notes

Installation should be performed by a licensed plumber or qualified pipefitter in accordance with applicable local plumbing codes and IPC guidelines. Shut off and depressurize the supply line fully before removing or installing any threaded fitting. Apply an appropriate thread sealant or PTFE tape to the male threads before assembly and tighten to hand-tight plus the number of turns appropriate for the pipe material and sealant used. Do not overtighten brass fittings, as the material can crack under excessive torque.
