Value Collection 314-1830 Round Die M22x1 2 Inch Hss

Product Description

The VALUE COLLECTION 314-1830 is a round threading die designed to cut external M22x1 metric fine threads on rod, bolt stock, or cylindrical workpieces. Manufactured from high-speed steel (HSS), this die maintains cutting edge hardness through the heat generated during threading operations. At 2 inches in outside diameter, it fits standard round die stocks of that size. The adjustable design allows the operator to set cutting tension and take multiple passes for a cleaner thread form. Right-hand thread direction matches the vast majority of fastener and fitting applications. This die is suited for machinists, pipefitters, and maintenance technicians working with metric fine thread specifications.

This die is used wherever an M22x1 external thread must be cut or chased — including hydraulic fittings, precision instrument housings, automotive components, and custom fastener fabrication. It is appropriate for bench work and field repair in both shop and light industrial environments. The metric fine pitch of 1 mm provides finer thread engagement and greater resistance to vibration-induced loosening compared to standard metric coarse threads of the same diameter.

Key Features

• M22x1 metric fine thread specification for precise external threading
• High-speed steel construction resists heat and wear during cutting
• Adjustable design allows cutting tension control and multi-pass threading
• Right-hand thread direction compatible with standard fastener orientation
• 2 inch outside diameter fits commonly available round die stocks

Compatibility

Designed for use in standard 2 inch round die stocks. Cuts M22x1 metric fine right-hand external threads on steel, aluminum, brass, and similar machinable materials.

Installation Notes

Threading dies are installed and operated by machinists and maintenance technicians using a properly sized round die stock or die holder. Secure the workpiece firmly before applying the die to prevent movement during thread cutting. Apply cutting oil throughout the operation to reduce friction, extend die life, and improve thread finish. Inspect the die for chipping or wear before each use and replace if the cutting edges are damaged.
