Value Collection 235-7062 Collet Block Chuck ER32

Product Description

The VALUE COLLECTION 235-7062 is a manual, non-indexing collet block chuck designed for horizontal workholding applications in machining and toolroom environments. Built from steel construction, this fixture accepts ER32 series collets with a minimum collet capacity of 3/32 inches and a maximum collet capacity of 13/16 inches. The collet block chuck provides a rigid, repeatable clamping solution for milling, grinding, and inspection setups where indexed positioning is not required. Machinists and toolroom technicians use this type of fixture to hold cylindrical workpieces or tools securely during secondary operations.

This collet block chuck is suited for horizontal orientation setups on milling machine tables, surface grinders, and precision workholding fixtures in job shop and production machining environments. The manual activation method makes it straightforward to tighten and release collets using a standard ER spanner wrench. Its compact footprint allows it to fit into confined fixture setups where space is limited. The ER32 collet series compatibility gives the user a wide range of available collet sizes to accommodate varying workpiece diameters within the stated capacity range.

Key Features

• ER32 collet series compatibility for a broad range of collet sizes
• Manual activation for simple, direct clamping without pneumatic or hydraulic components
• Horizontal orientation type for table-mounted and fixture-based setups
• Collet capacity range from 3/32 inches to 13/16 inches
• Steel construction for durability in machine shop environments
• Compact dimensions suited for space-constrained workholding configurations

Compatibility

Compatible with ER32 series collets. Designed as a standard collet block chuck for horizontal non-indexing workholding applications.

Installation Notes

Installation and setup of collet block chucks is typically performed by machinists or toolroom technicians. Ensure the machine table or fixture plate is clean and free of chips before mounting. Use the appropriate ER32 spanner wrench to seat and tighten the collet to the workpiece — do not overtighten by using improvised tools. Verify the workpiece is fully seated within the collet bore before initiating any machining or grinding operation.
