Value Collection -13358-3D Cast Iron Pipe Bushing 1-1/4x1/2

Product Description

The VALUE COLLECTION -13358-3D is a black cast iron threaded pipe bushing designed to reduce a 1-1/4 inch female threaded port down to a 1/2 inch male threaded connection. Rated at Class 150 with a 300 psi liquid and gas pressure rating, this bushing handles standard service demands in both plumbing and mechanical piping systems. The black finish is typical of cast iron fittings used in gas distribution, compressed air, and general industrial piping. Licensed plumbers and pipefitters install this type of fitting during new construction and retrofit work where pipe size transitions are required.

This bushing is suited for residential and light commercial piping applications involving threaded black iron pipe systems. Common uses include natural gas supply lines, propane distribution, compressed air headers, and water service piping where cast iron fittings are specified. The 1-1/4 inch by 1/2 inch reducing configuration makes it a standard fitting in mechanical rooms, utility connections, and service branch takeoffs. This item is sold in a package quantity of 5.

Key Features

• 1-1/4 inch to 1/2 inch reducing bushing for threaded pipe systems
• Cast iron construction with black finish for gas and industrial piping service
• Class 150 rated with 300 psi liquid and gas pressure rating
• Threaded end connections compatible with standard NPT pipe threads
• Sold in a package quantity of 5 units

Compatibility

Designed as an OEM-style replacement or standard-service fitting for threaded black iron pipe systems requiring a 1-1/4 inch to 1/2 inch reducing bushing at Class 150 pressure rating.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and IFGC or IPC requirements. Shut off all gas or fluid supply and depressurize the line before removing or installing any threaded fitting. Apply an appropriate pipe thread sealant or PTFE tape rated for the service medium before making up the joint. Do not over-tighten cast iron fittings, as the material is brittle and susceptible to cracking under excessive torque.
