Value Collection 111CB25160 Pressure Gauge 160 Psi

Product Description

The VALUE COLLECTION 111CB25160 is an analog pressure gauge designed for monitoring system pressure in plumbing, HVAC, and general mechanical applications. The gauge features a 2.5-inch black dial with a 0 to 160 psi range and delivers an accuracy rating of plus or minus 3-2-3 percent of scale. A 1/4-inch NPT center back mount connection allows for straightforward installation into standard pipe or manifold ports. The ABS case houses a bronze Bourdon tube, and all wetted parts are brass, making it suitable for a range of common system fluids. The unit is not liquid filled. Weighing 0.2 pounds, it is a compact, lightweight instrument suited for tight installations.

This gauge is appropriate for residential and light commercial plumbing, HVAC hydronic systems, compressed air lines, and general fluid systems where a dry-face analog pressure indicator is needed. The center back mount orientation suits panel-mount or pipe-stub installations where a flush or recessed gauge presentation is preferred. Licensed plumbers, HVAC technicians, and mechanical contractors routinely use gauges of this type during system commissioning, diagnostic work, and permanent monitoring installations.

Key Features

• 0 to 160 psi pressure range suits common plumbing and HVAC system pressures
• Plus or minus 3-2-3 percent of scale accuracy for reliable system monitoring
• 2.5-inch analog dial provides clear, at-a-glance pressure readings
• 1/4-inch NPT center back mount fits standard pipe and manifold connections
• Brass wetted parts and bronze Bourdon tube for compatibility with common system fluids
• Lightweight ABS case at 0.2 pounds for compact, low-profile installation

Compatibility

Designed as a standard replacement or new-install dry-face analog pressure gauge for systems with 1/4-inch NPT center back mount gauge ports operating within a 0 to 160 psi range.

Installation Notes

Installation should be performed by a licensed plumber or qualified HVAC or mechanical technician. Depressurize and isolate the system completely before removing an existing gauge or installing this unit. Apply appropriate thread sealant tape or compound to the NPT threads per local plumbing code requirements. Do not overtighten the gauge connection, as excessive force can damage the Bourdon tube or crack the case.
