Value Collection 1108MSB 10-32 X 1/2 in Binding Head Slotted Screw

Product Description

The VALUE COLLECTION 1108MSB is a binding head machine screw designed for general-purpose fastening applications where a slotted drive and low-profile head are required. Sized at 10-32 thread and 1/2 inch length under head, this screw is manufactured from steel with a zinc finish for basic corrosion resistance. The binding head style features a slightly larger diameter than a pan head, with a flat or very slightly rounded top and a pronounced bearing surface, making it well-suited for applications where the head must seat flush against thin material or hold a wire or conductor in place. Meets ASME B18.6.3 and SAE J82 standards. Sold in a minimum order quantity of 100 pieces.

This screw is commonly used by electricians, HVAC technicians, and mechanical trades for panel work, equipment enclosures, terminal connections, and light structural assembly. The binding head profile is a traditional choice for electrical binding posts and control panel components. The slotted drive is compatible with standard flat-blade screwdrivers and is frequently specified in equipment where magnetic-tip drivers must be avoided or where slotted fasteners are called out by original equipment specifications.

Key Features

• 10-32 unified fine thread for secure engagement in tapped holes
• 1/2 inch length measured under head per ASME B18.6.3 and SAE J82 standard
• Binding head style provides wide bearing surface for thin-material and terminal applications
• Slotted drive compatible with standard flat-blade screwdrivers
• Steel construction with zinc finish for light corrosion protection
• Material grade J82 per SAE specification

Compatibility

Designed as a standard 10-32 binding head machine screw suitable for use in electrical enclosures, control panels, and mechanical assemblies that specify an ASME B18.6.3 or SAE J82 compliant fastener without a washer.

Installation Notes

Installation is typically performed by electricians or mechanical technicians using a flat-blade screwdriver sized to the slot. Ensure the mating tapped hole or nut meets the 10-32 thread specification before installation. Do not overtighten, as the steel screw can strip threads in soft metal or plastic substrates. When used in electrical applications, follow applicable NEC requirements for conductor terminations and fastener torque as specified by the equipment manufacturer.
