UNITED STRUCTURAL PRODUCTS A62-09-HTR12-36-06-G Horizontal Reducing Tee Cable Tray Fitting

Product Description

The UNITED STRUCTURAL PRODUCTS A62-09-HTR12-36-06-G is a horizontal reducing tee fitting used in cable management systems. This fitting connects a main cable tray with a width of thirty-six inches to a six-inch wide branch. It features a twelve-inch radius, making it suitable for various installations. Constructed from aluminum with arc-welded methods, it provides reliability within the cable tray infrastructure. It is part of the US Tray line and meets NEMA standards, certified by Underwriters Laboratories.

• Designed to connect a 36-inch wide main cable tray run to a 6-inch wide branch.
• Manufactured with arc-welded aluminum for durability.
• Meets NEMA standards and is UL certified for equipment grounding conductor use.

Product Highlights

This fitting is essential for effective cable management, ensuring safety and compliance.

Product Information

Standard Information

• Product Type: Horizontal Reducing Tee Cable Tray Fitting
• Brand: UNITED STRUCTURAL PRODUCTS

Technical Specifications

• MPN: A62-09-HTR12-36-06-G
• Material: Aluminum
• Fitting Class: 09
• Radius: 12 inches
• Width 1 (Main Run): 36 inches
• Width 2 (Reducing Branch): 6 inches
• Construction: Arc-welded
• Compliance: NEMA standards, UL Certified (NEC 392.7, CSA Std. C22.2 No. 126)
• Hardware: Geomet Hardware
