U.S. Motors D1P2G General Purpose Three Phase ODP Horizontal - Footed Motor

Product Description

The U.S. Motors D1P2G is a general purpose three phase ODP horizontal footed motor. This motor operates at one horsepower and a speed of one thousand eight hundred rpm. The voltage rating is five hundred seventy-five volts, making it suitable for various applications.

• Designed for continuous duty applications.
• Features four poles for efficient performance.
• Constructed with an open drip-proof enclosure for effective cooling.

Product Highlights

Ideal for various industrial applications where reliability and performance are crucial. This motor is built for durability and efficiency, meeting the demands of frequent use.

Product Information

Standard Information

• Brand: U.S. Motors
• Motor Application: General Purpose

Technical Specifications

• HP: 1
• Voltage Rating: 575
• RPM: 1800
• Frame: 143T
• Enclosure Designation: ODP - Open Drip Proof
• Full Load Amps: 1.3
• Service Factor: 1.15
• Efficiency: 85.5 %
• Weight: 35.0 lb
