Tyco 57740ACP Grinnell G-Fire 4 x 4 in. Painted Lightweight Rigid Coupling

Product Description

The Tyco 57740ACP is a Grinnell G-Fire lightweight rigid coupling designed for fire protection systems. This four by four inch coupling provides a rigid joint by gripping the pipe grooves along the full circumference. It joins pipes and serves as an alternative to welding, threading, or flanges. The coupling is constructed from carbon steel, ductile iron, and rubber with a painted coating and includes a standard grade A EPDMA pre-lubricated gasket.

• Designed for use in fire protection systems.
• Provides a rigid joint by firmly gripping along the pipe grooves.
• End connections are grooved.

Product Highlights

This coupling is suitable for joining pipes in various fire protection applications, ensuring secure connections.

Product Information

Standard Information

• Brand: Tyco / Grinnell
• MPN: 57740ACP

Technical Specifications

• Application: Fire Protection
• Collection: Grinnell G-Fire
• Fitting Type: Coupling
• Fitting Size 1: 4 in
• Fitting Size 2: 4 in
• End Connection 1: Grooved
• End Connection 2: Grooved
• Material: Carbon Steel, Ductile Iron, Rubber
• Material Type: EPDM
• Coating: Painted
• Pressure - Maximum: 300 psi
• Length: 1.83 in
• Weight: 3.3 lb
• UL Listed: Yes
• FM Approved: Yes
• NSF Certified: No
• Origin: Global
• ASTM: ASTM A-153, ASTM A-183 Grade 2, ASTM A-536 Grade 65-45-12
