Ty-Rap TY5275MX Cable Tie 18in 0.27in

Product Description

The TY-RAP TY5275MX cable tie is a high-performance standard cable tie with an 18-inch length and 0.27-inch width. Designed with innovative materials, it provides a fastening solution for applications where performance matters. The low-profile head prevents snags, and the stainless steel locking device ensures maximum strength. It is suitable for use in temperatures from -76 to 185 deg F.

• Low profile head prevents snags on uneven surfaces.
• Non-magnetic stainless steel locking device ensures maximum strength.
• Weather and UV-resistant.

Product Highlights

This Ty-Rap cable tie offers superior performance with its innovative design, stainless steel locking mechanism, and resistance to weather and UV exposure.

Product Information

Standard Information

• Brand: TY-RAP
• Manufacturer Part Number: TY5275MX
• Country of Origin: United States

Technical Specifications

• Type: High Performance Standard
• Width: 0.27 in
• Length: 18 in
• Thickness: 0.06 in
• Manufacturer: ABB - Installation Products
• Lock Mechanism: Stainless Steel Barb
• Bundle Diameter: 0.236 to 5 in
• Tensile Strength: 120 lb
• Temperature Rating: -76 to 185 deg F
• Material: Nylon/Polyamide 6.6
• Country of Origin: United States
• Made in USA: Yes
• Standard: UL E49405
• UPC: 786210870854
• GTIN: 00786210870854
• Item Type: High Performance
• Clip Material: Stainless Steel
• Approval: UL, CSA
• Finish: Natural
• Size [Features]: 18"
• Type [Features]: Cable Ties
• Material [Features]: Nylon
• Product Type [Features]: Tie
• Tensile Strength (lbs) [Features]: 120 lbs.
• RoHS: RoHS3 Compliant
• REACH: REACH 247 Compliant
• TSCA: TSCA Section 6(h) Compliant
• ETIM: EC000046 Cable tie
• Band width: 0.272 in
• Length belt/tape/tie: 18 in
• Tie thickness: 0.059 in
• Max. bundle diameter: 5 in
• Min. holding force: 119.15 lb
• Operation temperature: -76 to 185 °F
• Material quality: Polyamide (PA)
• Surface protection: Untreated
• Halogen free: Y
• Transparent: N
• Reflective (fluorescent): N
• Text strip: None
• Solvable fastener: N
• MIL approval: N
• UL approval: Y
• Inflammability class of insulation material acc. with UL94: Other
• Holding Force: 116.9 lb
• Package Quantity: 50
• Series: TY275 Series
