Tweco 1240-1316 Robotic Mig Nozzle 600A 5/8 Inch Bore

Product Description

The TWECO 1240-1316 is a 3-piece robotic MIG welding nozzle designed for use with robotic and fixed automation MIG guns. It handles medium- to heavy-duty welding applications rated up to 600 amps and is built specifically for installations where a shorter electrical stick-out is required. The nozzle housing is machined from tellurium copper alloy bar for effective heat dissipation. The insert is machined from solid brass with internal threads matched to the gas diffuser. A G7 silicone insulator provides electrical isolation from the gas diffuser, eliminating the need for an additional insulator.

This nozzle is suited for robotic weld cells running continuous or high-cycle MIG processes in medium- to heavy-duty production environments. Its flush tip configuration places the contact tip closer to the work piece, making it appropriate for shorter arc lengths and tighter electrical stick-out requirements. The bottle-shaped geometry and straight I.D. bore at the nozzle front are optimized for use with automated nozzle cleaning stations commonly integrated into robotic weld cells. The part number is roll-stamped on the outside surface for quick field identification.

Key Features

• Rated up to 600 amps for medium- to heavy-duty welding applications
• 3-piece design: tellurium copper alloy housing, solid brass insert, G7 silicone insulator — no additional insulator required
• Flush tip configuration with flush to 1/16 inch tip recess for shorter electrical stick-out
• 5/8 inch bore diameter with straight I.D. bore for proper sidewall cleaning and consistent shielding gas flow
• Bottle-shaped geometry compatible with automated nozzle cleaning stations in robotic weld cells
• Part number roll-stamped on exterior for fast identification during changeout
• Designed for robotic and fixed automation MIG gun platforms

Compatibility

Designed for use with robotic and fixed automation MIG guns requiring a REL24 nozzle configuration. Consult TWECO documentation to confirm fitment with specific gun models and gas diffuser thread patterns before installation.

Installation Notes

Installation is typically performed by a qualified welding technician or automation maintenance technician. Shut down and de-energize the welding power source and robot before servicing front-end consumables. Thread engagement between the nozzle insert and gas diffuser should be confirmed snug and properly seated before resuming operation. Inspect the G7 silicone insulator for damage during each nozzle changeout to maintain proper electrical isolation.

Technical Specifications

• Current Rating: 600 amps
• Bore Diameter: 5/8 inches
• Tip Configuration: Flush (flush to 1/16 inch recess)
• Nozzle Design: 3-piece
• Housing Material: Tellurium copper alloy
• Insert Material: Solid brass
• Insulator Material: G7 silicone
• Geometry: Bottle shaped, straight I.D. bore
• Length: 1 inch
• Width: 3.2 inches
• Weight: 0.24 pounds
• Sold As: Each
• UPC: 608246329055

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1240-1316
