Tweco 1020-1144 Mig Gun 200A 15 Ft Lincoln

Product Description

The TWECO 1020-1144 is a 200-amp, air-cooled MIG welding gun from the Professional No. 2 Series, designed for semi-automatic welding in medium fabrication environments. The gun accepts wire sizes from 0.030 to 0.035 inches and comes with a 15-foot lead cable featuring a Lincoln-style rear connection. It is rated at 60% duty cycle using CO2 gas. A 60-degree metal jacket conductor tube with full 360-degree swivel, a silver-plated trigger, and a fully insulated Mig-Kwik connection at the wire feeder make this gun serviceable and practical for daily production use. Licensed welders and fabrication professionals handling medium-duty MIG applications are the primary users.

The 1020-1144 is suited for a broad range of applications including shop fabrication, maintenance and repair, farm and agricultural work, artistic metalworking, and light-to-medium production runs. The Lincoln-style rear connection makes it a direct fit for wire feeders using that connection standard. The oval-shaped handle is balanced to pivot at the center, reducing operator fatigue during extended use in varied welding positions. A gun hanger located at the bottom of the handle allows safe resting when the gun is not in use.

Key Features

• 200-amp output rated at 60% duty cycle with CO2 gas
• Accepts 0.030 to 0.035 inch wire diameter
• 15-foot lead cable with Lincoln-style rear connection
• 60-degree metal jacket conductor tube with full 360-degree swivel around handle for easy repositioning
• Silver-plated trigger contacts with self-cleaning action on every engagement and disengagement
• Steel spring strain relief supports the Cablehoz at the rear of the handle to reduce wire feed issues
• Fully insulated Mig-Kwik connection for quick connect and disconnect at the wire feeder

Compatibility

Designed for use with Lincoln-style wire feeders. Compatible with a wide selection of standard No. 2 Series front-end consumables including contact tips, nozzles, and liners suited to 0.030 to 0.035 inch wire.

Installation Notes

Installation and service of MIG welding equipment should be performed by a qualified welder or welding technician. Power down and disconnect the wire feeder from its power source before connecting or disconnecting the gun cable. Verify that the Lincoln-style rear connection is fully seated and secured before initiating a weld. Follow applicable ANSI and AWS safety standards for welding equipment setup and operation.

Technical Specifications

• Amperage: 200 A
• Duty Cycle: 60% with CO2 gas
• Wire Size Range: 0.030 to 0.035 inches
• Lead Cable Length: 15 feet
• Conductor Tube Angle: 60 degrees
• Cooling Type: Air-cooled
• Connection Style: Lincoln rear connection
• Weight: 10.1 pounds

Standard Information

• Brand: TWECO
• Manufacturer Part Number: 1020-1144
