Tuttokool A4AH4P31E1B00A Air Handler 2.5 Ton REPLACEMENT MPN

Product Description

The TUTTOKOOL A4AH4P31E1B00A is a versatile 2.5-ton air handler designed for efficient year-round comfort in both heat pump and straight-cool systems. Compatible with R-410A systems and delivering up to 14.3 SEER2 efficiency, this air handler ensures reliable performance and energy savings. It features a multi-position design, a direct-drive blower, and is optimized for smooth integration into tight spaces.

• 2.5 tons of cooling
• Multi-position flexibility
• 14.3 SEER2 efficiency

Product Highlights

The TUTTOKOOL A4AH4P31E1B00A air handler provides efficient, reliable, and flexible comfort for residential and light commercial HVAC systems.

Product Information

Standard Information

• Brand: TUTTOKOOL
• Manufacturer Part Number: A4AH4P31E1B00A

Technical Specifications

• Brand: TUTTOKOOL
• Model: A4AH4P31E1B00A
• Cooling Capacity: 30000 BTU/h
• Efficiency Rating: Up to 14.3 SEER2
• Refrigerant Type: R-410A
• Installation Type: Multi-Position (Upflow, Downflow, Horizontal)
• Blower Type: Direct-Drive
• Metering Device: Factory-Installed TXV
• Applications: Residential / Light Commercial HVAC systems
• Type: Heat Pump
• Ton: 2.5 Ton
• SEER: 14.3
• Cooling Stage(s): 1
• Compressor Stage: Single
• Electrical Phase(s): 1-Phase
• Suction Valve Size (Inches): 3/4
• Liquid Valve Size (Inches): 3/8
• Heating Btu: 30000
• Blower: Multi-Speed
• Amperage Rating: 2.9 A
• CFM Rating: 1409 cfm
• Connection Type: FNPT, Sweat
• Finish: Galvanized
• Frequency Rating: 60 Hz
• Fuse Rating: 15 A
• HP Rating: 1/5 hp
• Liquid Line Size: 3/8 in
• Material: Aluminum/Metal/Steel
• Motor Type: PSC
• Nominal Capacity: 2.5 to 3 ton
• Number of Speeds: 3
• Phase: 1 ph
• Pressure Rating: 0.6 in-WC
• Rotational Speed: 903 rpm
• Suction Line Size: 3/4 in
• Voltage Rating: 208/230 V
