Tru Audio ms.1 Network Audio Streamer Hdmi Earc

Product Description

The TRU AUDIO ms.1 is a dedicated network audio streamer designed to bring modern streaming sources into distributed audio, outdoor audio, and smart-home sound systems. It accepts HDMI eARC, optical, USB, analog RCA, and network inputs, then outputs via optical, digital coax, or analog RCA to downstream amplification. Onboard wireless protocols include AirPlay, Google Cast, Spotify Connect, Tidal Connect, and Bluetooth LE Audio with Auracast support. A high-performance DSP and high-resolution DAC handle signal processing internally. Licensed audio integrators and AV system technicians are the primary installers.

The ms.1 is suited for residential and light-commercial distributed audio installations where a single, compact source device needs to feed zone amplifiers or AV receivers. Typical applications include whole-home audio systems, outdoor speaker zones fed from an indoor rack, and retrofit projects adding network streaming to legacy speaker infrastructure. The unit can be powered via PoE from a network switch or via USB-C, offering flexible rack or shelf placement without a dedicated power run.

Key Features

• HDMI eARC input passes TV audio directly into the distributed audio system
• AirPlay, Google Cast, Spotify Connect, and Tidal Connect supported natively
• Bluetooth LE Audio with Auracast for low-latency wireless source connection
• High-resolution DAC with onboard DSP for clean signal output
• Dual power options: PoE or USB-C eliminate dedicated power supply in most installs
• Compact form factor at 5.75 inches wide by 1.75 inches high by 5.75 inches deep suits rack shelves or equipment closets

Compatibility

Designed as a source component for distributed audio systems, outdoor audio systems, and smart-home AV installations requiring network streaming inputs fed into zone amplifiers or AV receivers.

Installation Notes

Installation is typically performed by a licensed AV integrator or low-voltage systems technician. Power down or deprovision the destination amplifier zone before connecting analog or digital outputs to avoid signal transients on connected speakers. When using PoE power, confirm the supplying switch port meets the power draw requirements of the device. Follow local low-voltage wiring codes and manufacturer rack-mounting guidelines when positioning the unit in an equipment enclosure.

Technical Specifications

• Speaker Type: Network audio streamer
• Inputs: HDMI eARC, optical, USB, analog RCA, network, IR
• Outputs: Optical, digital coax, analog RCA
• Wireless Protocols: AirPlay, Google Cast, Spotify Connect, Tidal Connect, Bluetooth LE Audio with Auracast
• Power Options: PoE, USB-C
• Width: 5.75 inches
• Height: 1.75 inches
• Depth: 5.75 inches

Standard Information

• Brand: TRU AUDIO
• Manufacturer Part Number: ms.1
