Trerice 842615105301 450 Process Gauge (4-1/2 in) 450B4502LA400

Product Description

Trerice 842615105301 is a Series 450 process pressure gauge with a 4-1/2 inch dial and a 0 to 400 psi range. The lower-mount gauge features a 1/4 in MNPT connection, +/-0.5% accuracy, and a 250 deg F temperature rating. Construction includes a fiberglass reinforced polypropylene solid-front case with blow-out back, bronze tube with brass socket, stainless steel movement, and an acrylic window for industrial process and petrochemical applications.

• 4-1/2 in dial, range 0 to 400 psi, accuracy +/- 0.5%
• Lower mount 1/4 in MNPT connection; Series 450 process gauge
• Fiberglass reinforced polypropylene solid-front case, bronze tube with brass socket, stainless steel movement, acrylic window

Product Highlights

4-1/2 in dial, 0-400 psi range, 1/4 in lower NPT connection, +/-0.5% accuracy, 250 deg F rating

Product Information

Standard Information

• Brand: TRERICE
• Manufacturer Part Number: 842615105301
• Country of Origin: USA

Technical Specifications

• Brand: Trerice
• Manufacturer Part Number: 842615105301
• Alternate Part Number: 450B4502LA400; 450B-45-02-L-A-150
• Series: 450
• Product Name: Process Gauge
• Dial Diameter: 4-1/2 in (114.3 mm)
• Pressure Range: 0 to 400 psi
• Connection Size: 1/4 in MNPT (1/4 in NPT)
• Mounting Type: Lower mount
• Accuracy: +/- 0.5 %
• Temperature Rating: 250 deg F
• Case Material: Fiberglass reinforced polypropylene, solid front with blow-out back
• Tube Material: Bronze tube with brass socket
• Movement Material: Stainless steel movement
• Window Material: Acrylic
• Overload/Underload Protection: Overload and underload stops
• Pointer: Micro adjustable black finished pointer
• Dial: Aluminum white background dial with black graduations and markings
• Dimensions: 5.83 in diameter x 3.25 in depth
• Category: Mechanical Pressure Gauges
• Application: Petrochemical and industrial process industries
• Standards / Approvals: ASME B40.100 Grade 2A; CRN Registered
• Country of Origin: USA
• UPC: 842615105301
