Transolid fpt6032l-pc 60x32 Pre-tiled Shower Base Left Drain

Product Description

The TRANSOLID fpt6032l-pc is a pre-tiled, pre-grouted shower base measuring 60 inches in length by 32.25 inches in width, constructed from real marble tile bonded to an SMC (sheet molding compound) base using a flexible epoxy adhesive and grout. The base arrives factory-finished with an off-white hexagonal marble tile layout in the Pebble Creme colorway, which incorporates both brown and grey tones. It ships with a polished stainless-steel drain assembly sized for a 2-inch PVC connection. The unit weighs 200 pounds and is rated for a weight capacity of 1,763.7 pounds. Installation is intended for alcove configurations, set into a thinset mortar bed. Licensed plumbers and tile contractors are the typical trade installers for this product.

The fpt6032l-pc is designed for alcove shower installations in both residential and commercial settings. It suits new construction and remodel projects where a finished, tile-look base is required without on-site tile work. The left-hand drain configuration positions the drain outlet on the left side of the base. The base is pre-leveled and pre-sloped toward the drain, reducing layout and mortar work on the job site. According to the manufacturer, it is compatible with Transolid Titan, Prodigy, Expressions, and SaraMar wall kit systems, making it straightforward to coordinate the base with a matching wall surround.

Key Features

• Real marble tile pre-installed over an SMC base using flexible epoxy grout and adhesive — no on-site tiling required
• Integrated 6-inch tiling flange with a waterproof envelope design to prevent water intrusion at the base-to-wall junction
• Structural ribs on the underside radiate from the drain opening, creating a flex-free foundation when set in thinset mortar
• Quartz threshold included in off-white with a subtle swirl pattern; 3.5-inch height and 4.5-inch depth accommodates most large shower door assemblies
• Polished stainless-steel drain assembly included, with a 2-inch PVC solvent-weld or flexible connection
• Rated for residential and commercial use; covered by a 5-year limited residential warranty and a 3-year commercial warranty

Compatibility

Designed for alcove shower installations and confirmed compatible with Transolid Titan, Prodigy, Expressions, and SaraMar wall kit systems. The 2-inch drain outlet accepts standard PVC solvent-weld or flexible drain connections.

Installation Notes

Installation of this shower base should be performed by a licensed plumber or qualified contractor in accordance with applicable local plumbing codes. Power down any relevant electrical circuits and shut off the water supply before beginning rough-in work. The base is designed to be set into a full thinset mortar bed on the subfloor — do not install over an unsupported or hollow substrate. Verify that the drain rough-in location matches the left-hand drain position before setting the base.

Technical Specifications

• Length: 60 inches
• Width: 32.25 inches
• Height (Threshold): 3.5 inches
• Threshold Depth: 4.5 inches
• Drain Size: 2 inches
• Drain Location: Left
• Material: Marble tile over SMC base
• Color: Pebble Creme
• Shape: Rectangle
• Weight: 200 pounds
• Weight Capacity: 1,763.7 pounds
• Installation Type: Alcove
• Drain Assembly Included: Yes
• ADA Compliant: No
• Residential / Commercial: Both
• Warranty: 5-year limited residential / 3-year commercial

Standard Information

• Brand: TRANSOLID
• Manufacturer Part Number: fpt6032l-pc
