Trane SFCAP55440 Run Capacitor 55 MFD 440 VAC (Round) CPT00239

Product Description

Trane SFCAP55440 is a run capacitor rated 55 MFD (55 uF) at 440 VAC and 50/60 Hz for HVAC motor run applications. It stores and releases electrical charge to start and run condenser fan and compressor motors in packaged units, heat pumps, and central air conditioners. The unit uses CBB65 metallized polypropylene construction, is round in shape, and features 1/4 in male tab terminals with an operating range of -40 C to 70 C.

• 55 uF (55 MFD) capacitance; 440 VAC rating; 50/60 Hz frequency
• CBB65 metallized polypropylene round housing with 1/4 in male tab terminals
• Intended for packaged units/RTUs, heat pumps, and central air conditioners; replaces CPT00239 (RC item 4975900)

Product Highlights

Motor run capacitor, 55 uF, 440 VAC, CBB65 round housing, 1/4 in terminals, replaces CPT00239

Product Information

Standard Information

• Brand: TRANE
• Manufacturer Part Number: SFCAP55440
• Country of Origin: United States

Technical Specifications

• Brand: Trane
• Manufacturer Part Number (MPN): SFCAP55440
• Part Type: Run capacitor
• Capacitance: 55 uF (55 MFD)
• Voltage Rating: 440 VAC
• Frequency: 50/60 Hz
• Model/Series: CBB65
• Shape: Round
• Housing/Dielectric: Metallized polypropylene (CBB65)
• Terminal Type: 1/4 in male tab
• Operating Temperature: -40 C to 70 C
• Compatible Product Types: Packaged unit/RTU, heat pump, central air conditioner
• Replaces Part Number: CPT00239
• Country of Origin: China
• Condition: New
