TRANE RLY2563 Time Delay Relay

Product Description

The Trane RLY2563 is a time delay relay used in HVAC systems. This relay controls electrical circuits by opening or closing contacts based on input signals. It regulates power to different components of the system, managing functions like heating and cooling. Its compact design allows for easy installation in control panels.

• Manages electrical circuits in HVAC systems.
• Facilitates communication between system components.
• Compact design for control panel installation.

Product Highlights

This relay is essential for controlling HVAC operations, ensuring reliable communication between various system parts.

Product Information

Standard Information

• Manufacturer: Trane
• Part Number: RLY2563

Technical Specifications

• Category: Controls & Indicators
• Subcategory: Time Delay Relay
• Type: Enclosed, Pilot, Control
• Number of Poles: 1
• Contact Configuration: SPST
• Terminal Type: Screw
• Mounting Type: Surface
• Material: Gold Flashed Silver Cadmium Oxide
• Coil Voltage: 10 to 30V AC/DC
• Frequency: 50/60 Hz
• Operating Time: 20 Msec
• AC Contact Rating: 10A at 277V AC, 480VA Pilot Duty at 277V AC
• DC Contact Rating: 10A at 28V DC
• Power Rating: Various ratings from 33 mA to 55 mA depending on the voltage
• Temperature Rating: -30 to 140 Deg. F
• Dimensions: 4 inches x 4 inches x 1.8 inches with 0.5 inch NPT nipple
• RoHS: TRUE
• Standards: CE, UL
