Trane MOT6003 Motor - 230V 1Ph 1/4 HP 825 RPM

Product Description

The Trane MOT6003 is a single-speed motor designed for various applications requiring reliable power. Operating at 208-230 volts, this 1/4 horsepower motor delivers a speed of 825 RPM. It features a thermally protected system, ensuring safe operation. The totally enclosed design protects the motor from dust and moisture, making it suitable for various environments.

• Single-speed motor operating at 825 RPM.
• Requires a 5mfd x 370 VAC capacitor for operation (not included).
• Features reversible rotation and thermal protection.

Product Highlights

This motor is ideal for HVAC systems, fans, and pumps. The reversible rotation offers flexibility in installation.

Product Information

Standard Information

• Brand: Trane
• MPN: MOT6003

Technical Specifications

• Horsepower: 1/4
• Input Voltage: 208-230V
• Phase: 1
• Speed: Single
• RPM: 825
• Current: 1.4 Amps
• Enclosure: Totally Enclosed
• Rotation: Reversible
• Bearing Type: Sleeve
• Shaft Dimensions: 0.5 inches x 5.5 inches
• Body Length: 4-5/8 inches
• Capacitor Requirements: 5mfd x 370 VAC (not included)
• Thermal Protection: Yes
• Mounting Type: Shaft Up/Down and Rheem Mount
• Diameter: 5-5/8 inches
• Motor Type: Permanent Split Capacitor (PSC)
