Trane MOT13185 1/3 HP 3-Speed PSC Motor

Product Description

The Trane MOT13185 is a 1/3 horsepower motor designed for direct drive blower applications. This motor operates on 208-230 volts and features a permanent split capacitor design.

• 3-speed operation with a maximum of 1075 RPM.
• Automatic overload protection included.
• Reversible rotation for flexible installation.

Product Highlights

The Trane MOT13185 is ideal for HVAC maintenance and repair tasks, providing reliable performance in various applications.

Product Information

Standard Information

• Brand: Trane
• MPN: MOT13185

Technical Specifications

• Horsepower: 1/3 HP
• Speeds: 3
• Current: 2.60 Amps
• Rotation: Reversible
• Capacitor: POC5
• RPM: 1075
• Bearings: Sleeve
• Diameter: 5-5/8 inches
• Enclosure: Open
• Load Factor: 1.0
• Mounting: Mounting Kit
• Service Factor: 1.00
• Shaft Length: 4.5 inches
• Motor Type: Permanent Split Capacitor
• Frame: 48
• Overload Protection: Automatic
• Phase: 1
• Shaft Diameter: 1/2 inches
• Shafts: 1
• Frequency: 60 Hz
• Shaft Dimension: 1/2 x 4-1/2 inches
• Length Less Shaft: 4-3/8 inches
• Input Voltage: 208 - 230 V
• Capacitor Required: 5MFD/370V
• Air Over: Continuous Air Over
• Mounting Rings: 2 1/2 Inch Mounting Rings
• Insulation: Class B Insulation
• Ambient Temperature: 40°C
