Trane MOT11730 Condenser Fan Motor 1/2 HP 230V

Product Description

The Trane MOT11730 is a condenser fan motor designed for air conditioning systems. This 1/2 horsepower motor operates at a voltage of two hundred thirty volts, single phase, with a speed of one thousand seventy-five RPM. Its design includes a totally enclosed structure, measuring five and five-eighths inches in diameter. The motor is electrically reversible and supports all-angle mounting. It features thermal protection and requires a capacitor start with a ten mfd, three hundred seventy VAC capacitor (not included).

• Horsepower: 1/2 HP
• Voltage: 230V, Single Phase
• Speed: 1075 RPM

Product Highlights

Ideal for HVAC applications, this motor ensures reliable operation in various settings.

Product Information

Standard Information

• Country of Origin: US
• UPC: 0840899112756

Technical Specifications

• Horse Power: 1/2
• Input Voltage: 230V
• Phase: Single
• Current: 3.50 Amps
• Speed: 1075 RPM
• Number of Speeds: Single
• Rotation: Electrically Reversible
• Mounting Type: All Angle Mounting
• Diameter: 5-5/8 inches
• Frame Size: 48
• Enclosure: Totally Enclosed
• Body Length: 5-5/8 inches
• Shaft Size: 1/2 inch x 6-1/2 inches
• Bearing Type: Sleeve
• Thermal Protection: Thermally Protected
• Capacitor Type: Capacitor Start
